01. Getting Started with SCOPEinR • SCOPEinR

library(ToolsRTM)
library(SCOPEinR)

SCOPEinR is a full R port of SCOPE 2.0 (Soil Canopy Observation, Photochemistry and Energy fluxes, van der Tol et al. 2009; Yang et al. 2021) – it couples soil reflectance, canopy optical BRDF, leaf photosynthesis, and a full energy-balance closure loop into one simulation. ToolsRTM’s series (this site’s other tutorial set) covers leaf/canopy radiative transfer alone; this series covers what SCOPE adds on top: energy balance, fluorescence, and photosynthesis, all coupled together.

Leaf/canopy/soil/meteo inputs (one LUT row)
              |
              v
      Fluspect-Cx + fourSAIL (optical BRDF)
              |
              v
        Energy balance solve
     (leaf/soil temperature, iterative)
              |
      +-------+-------+
      |               |
      v               v
TOC reflectance   Fluorescence (SIF)
      |               |
      +-------+-------+
              |
              v
    Photosynthesis (Actot)

1. Run one full SCOPE simulation

table.with.opts <- read.table(system.file("input", "setoptions.csv", package = "SCOPEinR"),
                               header = TRUE, sep = ",")
Table.LUT <- read.table(system.file("input", "LUT_input.csv", package = "SCOPEinR"),
                         header = TRUE, sep = ",")

invisible(capture.output(
  db.sim <- SCOPEinR::get.SCOPE(
    LUT           = Table.LUT[1, ],
    options.SCOPE = table.with.opts,
    optipar       = SCOPEinR::optipar2021.Pro.CX,
    leaf.model    = "fluspect-CX",
    canopy.model  = "fourSAIL",
    get.outputs   = "ALL",
    get.plots     = FALSE
  )
))
res <- db.sim[[1]]  # get.SCOPE() always returns a list-of-results, even for one LUT row

cat("Canopy layers:", res$data.canopy$nlayers, "\n")
#> Canopy layers: 30
cat("TOC reflectance at 550nm:", round(res$data.rad$refl[550 - 400 + 1], 4), "\n")
#> TOC reflectance at 550nm: 0.0438
cat("TOC reflectance at 800nm:", round(res$data.rad$refl[800 - 400 + 1], 4), "\n")
#> TOC reflectance at 800nm: 0.3588
cat("Canopy-average leaf temperature (Tcave):", round(res$data.fluxes$Tcave, 2), "degC\n")
#> Canopy-average leaf temperature (Tcave): 22.04 degC
cat("Net radiation, total (Rntot):", round(res$data.fluxes$Rntot, 1), "W/m2\n")
#> Net radiation, total (Rntot): 496.7 W/m2
cat("Canopy photosynthesis (Actot):", round(res$data.fluxes$Actot, 2), "umol m-2 s-1\n")
#> Canopy photosynthesis (Actot): 19.89 umol m-2 s-1
cat("Canopy fluorescence flux (EoutF):", round(res$data.rad$EoutF, 4), "W/m2\n")
#> Canopy fluorescence flux (EoutF): 0.3889 W/m2

A note on get.SCOPE()’s return structure: unlike foursail() (Tutorial 01 of the ToolsRTM series, a flat list(rdot=, rsot=)), get.SCOPE() returns SCOPE’s own internal nested-list structure directly – data.rad, data.thermal, data.fluxes, data.canopy, data.spectral, iter.ebal, … 19 top-level fields. This is deliberate: it’s exactly what the original MATLAB SCOPE model produces, so it stays directly comparable to SCOPE documentation and literature.

What you want	Where it is
TOC reflectance (full spectrum)	`res$data.rad$refl`
Bi-hemispherical / directional components	`res$data.rad$rdd` / `rsd` / `rdo` / `rso`
Wavelength grid	`res$data.spectral$wlS` (400-2400nm @ 1nm, then coarser to 50000nm)
Fluorescence spectrum	`res$data.rad$LoF_`, on `res$data.spectral$wlF` (640-850nm @ 1nm)
Sunlit/shaded leaf temperature per layer	`res$data.thermal$Tcu` / `Tch`
Soil temperature	`res$data.thermal$Tsu` / `Tsh`
Energy-balance totals	`res$data.fluxes$Rntot` / `lEtot` / `Htot` / `Gtot`
Photosynthesis	`res$data.fluxes$Actot`
Solver convergence	`res$iter.ebal$counter` (iterations to converge)

2. Four views of the same simulation

wl_optical <- 400:2400  # the uniform-1nm part of data.spectral$wlS
n <- length(wl_optical)

op <- par(mfrow = c(2, 2))

plot(wl_optical, res$data.rad$refl[1:n], type = "l", col = "black", lwd = 1.5,
     xlab = "Wavelength (nm)", ylab = "Reflectance", main = "TOC reflectance components")
lines(wl_optical, res$data.rad$rdd[1:n], col = "steelblue")
lines(wl_optical, res$data.rad$rso[1:n], col = "firebrick")
legend("topright", c("refl (apparent)", "rdd (bi-hemispherical)", "rso (bidirectional)"),
       col = c("black", "steelblue", "firebrick"), lty = 1, cex = 0.7)

wlF <- res$data.spectral$wlF
plot(wlF, res$data.rad$LoF_, type = "l", col = "red3", lwd = 1.5,
     xlab = "Wavelength (nm)", ylab = "Fluorescence radiance (mW m-2 nm-1 sr-1)",
     main = sprintf("TOC fluorescence (F685=%.2f, F740=%.2f)", res$data.rad$F685, res$data.rad$F740))

layers <- seq_len(res$data.canopy$nlayers)
plot(layers, res$data.thermal$Tcu, type = "o", pch = 16, col = "darkorange",
     ylim = range(c(res$data.thermal$Tcu, res$data.thermal$Tch, res$data.thermal$Tsu, res$data.thermal$Tsh)),
     xlab = "Canopy layer (1 = top)", ylab = "Temperature (degC)",
     main = sprintf("Converged temperature profile (%d iterations)", res$iter.ebal$counter))
lines(layers, res$data.thermal$Tch, type = "o", pch = 16, col = "steelblue")
abline(h = res$data.thermal$Tsu, col = "brown", lty = 2)
abline(h = res$data.thermal$Tsh, col = "tan", lty = 2)
legend("topright", c("Tcu (sunlit)", "Tch (shaded)", "Tsu (soil, sunlit)", "Tsh (soil, shaded)"),
       col = c("darkorange", "steelblue", "brown", "tan"), lty = c(1, 1, 2, 2), cex = 0.7)

fluxes <- c(Rntot = res$data.fluxes$Rntot, lEtot = res$data.fluxes$lEtot,
            Htot = res$data.fluxes$Htot, Gtot = res$data.fluxes$Gtot)
barplot(fluxes, col = c("darkorange", "steelblue", "firebrick", "grey60"),
        ylab = "W m-2", main = "Canopy energy-balance totals")

par(op)

Reflectance, fluorescence, the converged temperature profile, and where the absorbed energy actually goes – all from one get.SCOPE() call. Tutorials 02-04 look at each of these in more depth; Tutorial 05 onward builds LUTs and runs many simulations at once.

What’s next

Tutorial 02 – the soil and canopy BRDF machinery behind refl, and SCOPE’s own input-table structure.
Tutorial 03 – the energy-balance solve behind the temperature profile above.
Tutorial 04 – fluorescence (SIF) in depth.
