Every tutorial so far ran the forward model: traits in, spectrum out. Inversion goes the other way – given ONLY the sensor-band reflectance a satellite or field spectrometer would measure, retrieve a biophysical trait (chlorophyll content, Cab, throughout this page) without knowing the ground truth. This is the hybrid approach: instead of solving the radiative transfer equations analytically (rarely possible) or field- calibrating an empirical index-to-trait relationship (needs field data per site/crop), simulate a LUT with the physics you already have, and learn the reflectance-to-trait relationship from the simulation itself.

Parameter LUT
     |
     v
RTM simulations (Tutorials 01-06)
     |
     v
Sensor convolution (Tutorial 07)
     |
     v
Synthetic training dataset (reflectance, trait) pairs
     |
     v
Inversion method
     |
     v
Vegetation traits

Three inversion methods share this exact framework, differing only in the last step:

  • get.inversionOpt() (this page): no model is fit at all. It ranks every spectrum in a reference LUT by how closely it matches an observed spectrum under a chosen merit function, then averages the trait values of the closest matches. Pure library search.
  • get.inversion() (Tutorial 12): fits a statistical/ML model (Random Forest, PLSR, SVM, … 12 algorithms via caret) on a training LUT, then predicts on new spectra.
  • getMLmodel() (Tutorial 13): fits a deep-learning model on the same kind of data.

1. Simulate a LUT and convolve to Sentinel-2A

n_samples <- 150
LUT <- as.data.frame(getLUT(inputs = ToolsRTM::inputsPROSAIL, nLUT = n_samples, setseed = 1))

wl <- 400:2500
rsoil <- rep(0.15, length(wl))
refl <- t(sapply(seq_len(n_samples), function(i) {
  foursail(inputLUT = LUT[i, ], rsoil = rsoil, LeafModel = "PROSPECT-PRO")$rsot
}))

refl_X <- as.data.frame(refl); colnames(refl_X) <- paste0("X", wl); refl_X <- cbind(id = seq_len(nrow(refl_X)), refl_X)
se2a <- suppressMessages(get.spectra.convolved(rfl = refl_X, sensor = "Sentinel2a", plot.spectra = FALSE))
#> [1] "Spectral resampling function to SENTINEL2A is being processed ..."
#>   |                                                                              |                                                                      |   0%  |                                                                              |=====                                                                 |   8%  |                                                                              |===========                                                           |  15%  |                                                                              |================                                                      |  23%  |                                                                              |======================                                                |  31%  |                                                                              |===========================                                           |  38%  |                                                                              |================================                                      |  46%  |                                                                              |======================================                                |  54%  |                                                                              |===========================================                           |  62%  |                                                                              |================================================                      |  69%  |                                                                              |======================================================                |  77%  |                                                                              |===========================================================           |  85%  |                                                                              |=================================================================     |  92%  |                                                                              |======================================================================| 100%
wl_bands <- as.numeric(names(se2a)[-1])
band_names <- paste0("B", seq_along(wl_bands))
names(se2a) <- c("id", band_names)

150 simulated spectra, convolved to Sentinel-2A’s 13 real bands – this is what every inversion method below actually sees, not the native 1nm spectrum.

2. A train/test split, shared by every method

set.seed(1)
train_idx <- sample(seq_len(n_samples), size = round(0.7 * n_samples))
test_idx  <- setdiff(seq_len(n_samples), train_idx)

LUT_train <- LUT[train_idx, ]; LUT_test <- LUT[test_idx, ]
se2a_mat <- as.matrix(se2a[, band_names])
se2a_train_mat <- se2a_mat[train_idx, ]; se2a_test_mat <- se2a_mat[test_idx, ]

r2_f   <- function(obs, pred) 1 - sum((obs - pred)^2) / sum((obs - mean(obs))^2)
rmse_f <- function(obs, pred) sqrt(mean((obs - pred)^2))

cat("Train:", length(train_idx), "spectra. Test (held out):", length(test_idx), "spectra.\n")
#> Train: 105 spectra. Test (held out): 45 spectra.

3. get.inversionOpt(): LUT merit-function matching

method picks how “closeness” between two spectra is measured. nOpt controls how many of the closest training spectra get averaged together for the final trait estimate:

opt_rmse <- get.inversionOpt(rfl.sensor = se2a_test_mat, rfl.rtm = se2a_train_mat,
                              LUT = LUT_train, wave = wl_bands, method = "merit-RMSE", nOpt = 5)
opt_fge  <- get.inversionOpt(rfl.sensor = se2a_test_mat, rfl.rtm = se2a_train_mat,
                              LUT = LUT_train, wave = wl_bands, method = "merit-FGE", nOpt = 5)
opt_dwt  <- get.inversionOpt(rfl.sensor = se2a_test_mat, rfl.rtm = se2a_train_mat,
                              LUT = LUT_train, wave = wl_bands, method = "merit-DWT", nOpt = 5)

Each call returns a 2-element list: [[1]] (rfl.b) is the matched reflectance itself, [[2]] (LUT.best) is the corresponding trait table:

opt_metrics <- data.frame(
  method = c("merit-RMSE", "merit-FGE", "merit-DWT"),
  R2   = c(r2_f(LUT_test$Cab, opt_rmse[[2]]$Cab), r2_f(LUT_test$Cab, opt_fge[[2]]$Cab), r2_f(LUT_test$Cab, opt_dwt[[2]]$Cab)),
  RMSE = c(rmse_f(LUT_test$Cab, opt_rmse[[2]]$Cab), rmse_f(LUT_test$Cab, opt_fge[[2]]$Cab), rmse_f(LUT_test$Cab, opt_dwt[[2]]$Cab))
)
knitr::kable(opt_metrics, digits = 3)
method R2 RMSE
merit-RMSE 0.287 14.472
merit-FGE 0.590 10.977
merit-DWT 0.251 14.832

merit-RMSE/merit-FGE compare raw band reflectance; merit-DWT compares each spectrum’s discrete wavelet transform coefficients instead (sensitive to overall spectral shape rather than each band’s exact value). merit-NRMSE, merit-MAE, merit-NMB, and merit-1stD (first-derivative matching) are the remaining built-in options; custom_stat accepts your own function(sim, obs).

plot(LUT_test$Cab, opt_rmse[[2]]$Cab, pch = 19, col = "#2166AC",
     xlab = "Observed Cab", ylab = "Predicted Cab (merit-RMSE, nOpt=5)",
     main = "LUT merit-function matching")
abline(0, 1, col = "grey40", lty = 2)

Why this method, and when

get.inversionOpt() needs no training step and works from a handful of reference spectra – a quick, physically-grounded retrieval with no ML infrastructure. Its limitation: accuracy is capped by how well the LUT covers the true trait space, and it re-searches the whole reference LUT for every new observation (no learned model to reuse). Tutorials 11-12 build actual models instead, trading that simplicity for better accuracy at scale.

What’s next

  • Tutorial 12 – get.inversion(): 12 ML algorithms, compared on this same LUT.
  • Tutorial 13 – getMLmodel(): deep learning on the same data.
  • Tutorial 14 – the full pipeline end-to-end, LUT to trait maps.
